As magnetic resonance imaging (MRI) systems and ultrasound diagnostic and therapeutic devices continue to evolve toward higher power densities and greater levels of integration, the thermal flux density experienced by internal power components is steadily increasing. Power modules must provide both reliable electrical insulation and efficient heat dissipation; any failure in either aspect can directly compromise image quality, treatment accuracy, or even patient safety.

Due to their simultaneous insulation and thermal conductivity, ceramic substrates are increasingly being used to support and dissipate heat from power modules within medical devices such as MRI and ultrasound systems. However, selecting a ceramic substrate alone is not sufficient; to fully leverage its thermal‑dissipation advantages, a systematic approach is required—covering material selection, thickness, metallization processes, and the overall thermal management architecture of the entire system.


I. Why are ceramic substrates required for power semiconductor devices?


Gradient power amplifiers and RF power amplifiers in MRI systems, as well as transmit circuits and high-voltage drive modules in ultrasound equipment, typically feature high voltage, large current, high switching frequencies, and concentrated heat generation. During operation, these power devices generate substantial heat; if this heat is not efficiently dissipated, rising junction temperatures can lead to parameter drift, reduced efficiency, and even thermal failure.

Meanwhile, medical devices impose extremely stringent requirements on electrical insulation safety. Parameters such as creepage distance, clearance, dielectric strength, and leakage current are all subject to regulatory compliance. Although the conventional “metal substrate + insulating pad” approach is relatively low-cost, the multiple interfaces introduce additional thermal resistance, and the insulating pad is prone to aging and dielectric breakdown under prolonged thermal cycling and humid‑heat conditions.

The core value of ceramic substrates lies in their ability to simultaneously provide electrical insulation and thermal conduction within a single material layer. In other words, the ceramic substrate leverages its intrinsic properties to rapidly dissipate heat from the chip’s thermal source, achieving both electrical insulation and efficient heat transfer. This integrated “insulation–thermal conduction” capability makes it an ideal choice for supporting and thermally managing power modules in medical applications.

II. The fundamental principle of heat conduction in ceramic plates: the material itself facilitates heat transfer.


Ceramic substrates conduct heat without relying on fans or liquids; instead, they utilize phonon-mediated heat transfer within the ceramic material to rapidly spread heat laterally beneath the chip and convey it vertically to the cold side. Compared with conventional FR4 substrates or traditional insulating pads, ceramic materials typically exhibit thermal conductivity that is one to two orders of magnitude higher.

A typical heat conduction path can be simplified as:

In this approach, the ceramic substrate simultaneously serves as both an electrical insulator and a thermal conductor, eliminating one or even multiple intermediate thermal interfaces. Compared with conventional designs, the ceramic substrate can significantly reduce the system’s thermal resistance, enabling heat generated by power devices to be dissipated more rapidly and uniformly.

However, it is important to clarify that the ceramic substrate itself is not the final heat‑dissipation component. Its role is to swiftly transfer heat away from beneath the chip; ultimately, the heat must still be removed via a heatsink, air cooling, liquid cooling, or convection within the chassis. Therefore, ceramic‑substrate‑based thermal management must be integrated into the overall system‑level thermal design and should not be considered in isolation.


III. Thermal conductivity varies significantly among different ceramic materials.


Not all ceramic substrates possess the same thermal dissipation capability. Thermal conductivity, dielectric strength, and mechanical reliability vary significantly among different ceramic materials, so selection should be based on the specific operating conditions.

As shown in the table, aluminum nitride and beryllium oxide stand out when considering thermal conductivity alone. However, medical devices cannot prioritize thermal performance at the expense of other critical factors. Although beryllium oxide boasts exceptionally high thermal conductivity, its dust is toxic, making it generally inadvisable for medical applications or requiring stringent control measures. Aluminum nitride offers excellent thermal performance but has relatively low mechanical strength, imposing stricter requirements on metallization processes, package designs, and moisture‑proofing. While silicon nitride’s thermal conductivity falls short of that of aluminum nitride, it excels in flexural strength, fracture toughness, and thermal shock resistance, making it ideally suited for applications involving frequent power cycling and demanding reliability standards. Alumina, by contrast, is more cost‑effective and well‑suited for medium‑ to low‑power modules.

Therefore, in MRI and ultrasound systems, high‑heat‑flux power modules typically prioritize aluminum nitride or silicon nitride, while also requiring a comprehensive assessment of mechanical strength, long-term reliability, and cost.


IV. Substrate thickness and metallization processes are often overlooked “hidden barriers” to thermal resistance.


Many engineers, when selecting components, focus solely on the ceramic material itself, overlooking the impact of substrate thickness and metallization processes on overall thermal conductivity. In fact, these two factors directly influence the thermal resistance performance of the ceramic substrate.

1. Substrate thickness

The thermal resistance of a ceramic substrate is approximately proportional to its thickness. For materials of the same composition, a 0.25 mm‑thick ceramic substrate exhibits significantly lower thermal resistance than one that is 0.635 mm or 1.0 mm thick. Thinning the substrate can effectively reduce conductive thermal resistance, thereby enhancing heat dissipation in power devices.

However, the thickness of ceramic substrates cannot be reduced indefinitely. Reducing the thickness compromises mechanical strength and dielectric withstand voltage, while also increasing the risk of chipping during machining and assembly. Medical devices demand exceptionally high reliability, necessitating a careful balance among thermal resistance, mechanical strength, and electrical insulation.


2. Metallization Process

The metallization layer on the ceramic substrate surface also influences thermal‑flow dissipation. Common metallization processes include DBC (direct‑bonded copper), DPC (direct‑plated copper), AMB (active metal brazing), and thick‑film metallization, among others.

• DBC : A thicker copper layer facilitates lateral thermal spreading and can carry high currents, but high-temperature processing may exert some stress on the ceramic substrate, necessitating careful control of thermal mismatch stresses.
• DPC : Metallized traces are fine and well-suited for high-density interconnections, but the copper layer is relatively thin, resulting in limited thermal dissipation capability.
• AMB : Balances thick copper layers with strong bonding strength, making it ideal for applications with demanding power cycling requirements and stringent reliability standards.
• Thick-film metallization : It has lower cost but a thermal conductivity inferior to that of pure copper, making it suitable for modules with relatively dispersed heat.

If the metallization layer covers only a localized area of the pad, the thermal flux will be “necked down” in that region, creating a hot spot. Consequently, the thickness and coverage area of the metallization layer, as well as its layout, must be carefully matched to the chip’s heat‑source distribution.


V. Ceramic Plates Are Not a “Panacea”: System Matching in Medical Applications


Medical equipment operates under unique conditions, and it is not sufficient to assume that simply selecting ceramic plates will resolve all thermal management challenges. In practical engineering applications, common misconceptions include:

1. Consider only the thermal conductivity of the ceramic, neglecting thickness and metallization thermal resistance. The overall thermal resistance of a ceramic substrate is determined jointly by its material, thickness, metallization layer, and interface; any weak link in this chain will compromise the final thermal‑dissipation performance.
2. It is believed that ceramic‑plate cooling can eliminate the need for heat sinks or air‑ and liquid‑cooling systems. The ceramic plate is merely a critical layer in the thermal pathway; ultimately, heat must still be removed via convection, radiation, or conduction.
3. Ignore the interface material. If low‑thermal‑conductivity thermal grease is used between the ceramic substrate and the heat sink, or if the assembly pressure is insufficient, or if the interface surface finish is poor, the interfacial thermal resistance may negate the thermal‑conductivity advantage offered by the ceramic substrate.
4. Ignore thermal expansion mismatch. The mismatch in thermal expansion coefficients among ceramics, copper, chips, solder, and heat sinks can give rise to thermal stresses, which, under prolonged power cycling, may lead to ceramic cracking or solder‑layer fatigue.

The correct approach is to perform thermal simulation and calculations based on the device’s actual heat dissipation power, heat flux density, junction‑temperature requirements, and operating duration, in order to determine the target thermal resistance. Subsequently, select appropriate ceramic materials, thicknesses, metallization processes, and interface materials in a reverse‑engineering manner, and integrate them with the overall system’s thermal management architecture in a scientifically sound way.


6. By making effective use of ceramic substrates, the thermal management circuit can be simplified, ensuring stable temperature control.


In MRI and ultrasound equipment, the core value of ceramic plates is reflected in the following aspects:

• Reduce the intermediate thermal interface layer : The ceramic plate integrates insulation and thermal conductivity, eliminating the insulating pads and additional interface layers required in conventional designs, thereby reducing the system’s thermal resistance.
• Enhance insulation reliability : Ceramic materials inherently possess high dielectric strength, thereby mitigating safety risks associated with the aging and breakdown of insulating pads.
• Power device carrier : Ceramic substrates serve as the mechanical support for power modules, enhancing integration and structural compactness.
• Stabilize device temperature : When matched with the overall thermal management architecture, the ceramic substrate helps keep the junction temperature of power devices within a safe range, reduces temperature fluctuations, and ensures long-term stable operation.

For example, in nuclear magnetic gradient power amplifier modules, power devices such as IGBTs or MOSFETs are mounted onto aluminum nitride or silicon nitride ceramic substrates via soldering or sintering. Heat is rapidly conducted to liquid‑cooled plates or air‑cooled heat sinks, while the ceramic substrate ensures reliable electrical insulation. Compared with conventional insulating pad solutions, this approach offers lower thermal resistance and more uniform temperature distribution, thereby enhancing device lifetime and system reliability.


Ceramic substrates represent a key technological pathway for thermal management in power‑electronics devices, yet they are not standalone components that can be “plug‑and‑play.” Only by fully understanding the performance limits of ceramic substrates and conducting systematic design and optimization—covering material selection, thickness, metallization processes, interfacial materials, and the overall thermal‑management architecture of the device—can their full cooling potential be realized.

For medical‑device manufacturers, integrating ceramic‑substrate selection into the early stages of overall thermal design—coupled with thermal simulation, power cycling, and long‑term reliability testing—is essential for mitigating thermal‑failure risks and ensuring the sustained, stable operation of MRI and ultrasound systems. Partnering with a thermal‑management supplier that possesses both thermal‑simulation capabilities and expertise in ceramic‑substrate fabrication can further shorten the development cycle, enabling ceramic substrates to fully leverage their unique thermal‑dissipation advantages in medical power modules.

If you have any inquiries, please feel free to contact us at 18001871611 or 18001873511.
